| Model |
SPD4 |
| Standard |
IEC61643-11; GB18802.11 |
| Protection Grade |
T2, Class II |
| Max Continuous Working Voltage Uc |
AC275V/AC385V |
| Nominal Discharge Current In 8/20μs |
20KA |
| Max Discharge Current In 8/20μs |
40KA |
| Voltage Protection Level Up |
2KV |
| Number of Poles |
L, N / L1, L2, L3, N |
| Response Time Ta |
≤25ns |
| Connecting Cable |
1.5mm²/9-7AWG |
| Method of Installation |
35mm DIN Rail |
| Operating Temperature Range |
-40°C ~ +80°C |
| Housing Color Module/Base |
White |
| Protection Class |
IP20 |
| Terminal Connection Type |
Phillips Screws |
| Tightening Torque |
3.0N.m |
| Certificate |
CE |
| Working Status Indicator Window |
Green (working well), Red (malfunction, product or module must be replaced) |
